Battery Connector 10 Pin with 4–10 Pin Flexibility

🔌 Battery Connector 10 Pin: Build Smarter from the Start

At Walta, we don’t just manufacture connectors—we build scalable platforms.
Our 10-pin battery connector system is engineered for flexibility: a single mold that supports 4 to 10 pins, giving engineers a future-ready solution that scales from entry-level devices to high-end smart modules without redesign.

Whether you’re building wearables, medical systems, or industrial battery packs, Walta’s connectors enable your battery to power, communicate, and evolve—through one compact, high-reliability interface.

🔋 Why a Custom Battery Connector 10 Pin is the Right Choice for Modern Devices

When designing compact smart devices, many teams begin with off-the-shelf connectors—until they hit a limit. Standard options like JST or Molex max out at 6 pins, which isn’t enough for today’s multi-function systems.

That’s where a dedicated 10-pin solution steps in, enabling not just power delivery but signal control, data exchange, and safety feedback—all through a single port.

📦 What Most Battery Connector 10 Pin Replacements Don’t Offer

Traditional connectors were built for basic power—not modern smart systems. Typical pinouts support:

  • 🔌 2–4 pins: power and ground

  • 🔌 5–6 pins: maybe NTC or charge control

But newer designs often need:

  • UART / I²C / SPI / SMBus

  • Temperature, current, or ID sensors

  • Hot-plug detection or status reporting

  • OTA firmware interfaces

A 10-pin battery connector offers the ideal balance—compact, but functionally complete.

⚙️ Walta’s Battery Connector Series: Product Overview

🔹 M30-0876-00051 – Male 10-Pin Battery Connector (DIP)

  • 10-pin, through-hole (DIP) mounting

  • Reliable mating performance, suitable for modular battery packs

  • Ideal for designs requiring firm contact retention and long insertion lifespan

  • Gold-plated terminals for enhanced conductivity and wear resistance

🔹 M30-0876-00001 – Female 10-Pin Battery Connector (DIP)

  • Matching female side, also DIP-mounted for strong mechanical stability

  • Designed to pair with M30-0876-00051 in embedded or replaceable battery systems

  • Supports frequent insertions and safe, stable contact under vibration

Together, these connectors provide a rugged and scalable platform, ideal for:

  • 🔋 Swappable smart battery packs

  • 🔬 Medical diagnostic systems

  • 🧠 Wearables and AR/VR modules

  • 🏭 AGV or robotics battery systems

🧩 Modular Flexibility: One Battery Connector 10 Pin Mold, Configurable from 4 to 10 Pins

Walta’s connector mold supports up to 10 pins, but is engineered to allow configuration from 4 to 10 pins—without changing the housing. That means:

  • ✅ Same housing for multiple product tiers

  • ✅ Simplified BOM and inventory

  • ✅ Lower tooling and NPI cost

Product Tier Pin Count Typical Functions
Entry-level wearable 4–5 pins Power + ID or NTC sensing
Mid-tier medical device 6–7 pins Charge control, UART/status detection
High-end module 8–10 pins Full power + comms + OTA + diagnostics

🔧 Smarter Architecture with Battery Connector 10 Pin Integration

Area Design Considerations
Pin Mapping Power (VBUS/GND), Data (I²C/UART), Control (NTC/ID), Reserve for future use
Durability ≥ 5,000 mating cycles, gold-plated contacts, robust locking design
Signal Integrity Differential pairs, EMI shielding, dedicated GND pin layout

📈 Why the Market Is Moving Toward Smart Multi-Pin Battery Connectors

  • Devices need more sensors, more logic, more feedback

  • Smart batteries are now expected to communicate health & charge status

  • Modular designs need connectors that scale with feature complexity

  • A single connector that handles both power and data reduces failure points

💡 Why Choose Walta ?

Walta delivers:

  • ✅ High-quality 10-pin male & female connectors with DIP stability

  • ✅ A single mold platform for 4–10 pins—scale without retooling

  • ✅ Engineering support to align with your system’s power, data, and EMI needs

When off-the-shelf parts can’t keep up with your innovation, a connector platform like Walta’s bridges the gap between practicality and performance.

Let’s connect—smarter. 🔌
Visit our website to learn more

🏢 About Walta Electronic

Walta Electronic specializes in high-quality connectivity solutions, providing a full range of USB Type-C, HDMI, DisplayPort connectors, Board-to-Board connectors, power connectors, as well as custom cables and wire harness assemblies. With precision manufacturing and advanced R&D, we serve premium applications across consumer electronics, medical technology, industrial control, Telecommunications, and automotive electronics — helping our partners stay competitive with performance they can trust.

👉 Follow us on LinkedIn for the latest product updates and connector insights.
